Crawler hydraulic 151 KW pile driver
Crawler hydraulic 151 KW pile driver
Crawler hydraulic 151 KW pile driver
Crawler hydraulic 151 KW pile driver
Crawler hydraulic 151 KW pile driver
  • Crawler hydraulic 151 KW pile driver
  • Crawler hydraulic 151 KW pile driver
  • Crawler hydraulic 151 KW pile driver
  • Crawler hydraulic 151 KW pile driver
  • Crawler hydraulic 151 KW pile driver

Crawler hydraulic 151 KW pile driver

    Payment Type: L/C,T/T
    Incoterm: FOB,CIF
    Min. Order: 1 Piece/Pieces
    Delivery Time: 14 Days

Basic Info

Model No.: DR-100

Type: Drill

Pressure Pile Driver Type: Hydraulic Pile Driver

Power Source: Diesel

Noise: With Noise

Certification: SGS, CE, ISO 9001:2008

Condition: New

Additional Info

Brand: DIngli

Transportation: Ocean,Land

Place of Origin: China

Supply Ability: 10 units per month

Certificate: ISO CQC CE SGS

Port: Qingdao,Shanghai,Tianjin

Product Description

Crawler hydraulic 151 KW pile driver DR-100 has a maximum turning depth of 30 meters and a drilling diameter of 500-1600 MM. It has a chassis telescopic function and the mast can adjust the vertical automatically. The mast is also equipped with an auxiliary hoist to assist in lifting the required items. The upper body has an automatic reset function. It is convenient for the Drill pipe to align with the drill hole and improve the work efficiency. The cabin is equipped with adjustable seats, and optional heating and ventilation systems are provided to improve operational comfort. The combination of a crawler-type telescopic chassis and an adjustable push shovel can cope with complicated working conditions and ensure construction safety.The products of Shandong Yahe Construction Machinery Co., Ltd. also have CE, ISO, SGS and other international quality certifications. The company has independent export rights, reliable product quality, superior performance, and affordable prices. Thank you for your browsing, the company is willing to reach long-term cooperation with you.



Hydraulic Pile Driver

Product Type DR-100
Chassis length.(mm) 4200
Track width.(mm) 600
Machine weight.(t) 26
Maximum drilling depth.(m) 30
drilling diameter.(mm) 500-1600
Engine brand Yuchai Weichai Cummins(Optional)
Engine rated power.(KW/rpm) 126 KW-151 KW
Maximum torque of power head.(KN.m) 100
Power head speed.(rpm) 10-50
Maximum working pressure of hydraulic system main pump.(MPa) 30
Maximum working pressure of hydraulic system auxiliary pump.(MPa) 12
Maximum bow rate of the main pump hydraulic system.(L/min) 80*2(Optional)
Maximum bow rate of the auxiliary pump hydraulic system.(L/min) 16
Maximum pressure of the pressurization system.(KN) 100
Maximum lifting force of the pressurization system.(KN) 80
Maximum travel pressure system.(mm) 3000
Maximum lifting force of the main winch.(KN) 150
Maximum pull-up speed of the main winch. (m/min) 50
Maximum lifting force of the auxiliary winch.(KN) 15
Maximum pull-up speed of the auxiliary winch.(m/min) 50
Left and right inclination angle of drilling mast(°) ±5
Forward and backward inclination angle of the drilling mast. (°) 5/90
Maximum driving speed(KM/h) 1.5
Maximum climbing angle.(°) 25
Maximum Driving torque.(KN.m) 40000-45000
Overall width of working state.(mm) 2800
Overall length of transport status.(mm) 11500
Overall width of transport status.(mm) 2800
Overall height of transport status.(mm) 3400
Drill rod type Machine Lock
Drill rod whether to provide custom Yes
drill tools

500-1800 mm Auger/Bucket drilling bit、Drilling Barrel、Coring drill、Reaming drilling bit

Looking for ideal Crawler Pile Driver Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Hydraulic Pile Driver are quality guaranteed. We are China Origin Factory of 151KW Pile driver. If you have any question, please feel free to contact us.
